ZYXEL Tűztfal 1x2.5-GbE port + 6x1-GbE +1xPOE+ 1xUSB 3.0 + 1konzol port, USGFLEX200HP-EU0101F

Hardware Specifications

Interface ports

200H:

2 x 2.5-GbE Ethernet

6 x 1-GbE Ethernet

200HP:

1 x PoE+ Ethernet (802.3at, 30W max.)

USB 3.0 ports

1

Console port

Yes (RJ-45)

Rack-mountable

Yes

Fanless

Yes

System Capacity & Performance^*1

SPI firewall throughput (Mbps)^*2

5,000

VPN throughput (Mbps)^*3

1,200

IPS throughput (Mbps)^*4

2,000

Anti-Malware throughput (Mbps)^*4

1,500

UTM throughput (Anti-malware & IPS, Mbps)^*4

1,500

Max. TCP concurrent sessions^*5

600,000

Max. concurrent IPsec VPN tunnels^*6

100

Recommended gateway-to-gateway IPsec VPN tunnels

50

Concurrent SSL VPN users

50

VLAN interface

32

Max. Concurrent devices logins^*7

200

Security Service^*8

Anti-Malware

Yes

IPS

Yes

Application Patrol

Yes

Web filtering

Yes

Reputation Filter

Yes

SecuReporter

Yes

Sandboxing

Yes

Device Insight

Yes

Secure WiFi^*9

Yes

Key Features

VPN

IKEv2, IPSec, SSL

SSL (HTTPS) inspection

Yes

Two-Factor Authentication

Yes

Nebula Centralized Management

Yes

Power Requirements

Power input

200H: 12V DC, 2A max.

200HP: 19V DC, 3.42A

Max. power consumption (Watt Max.)

200H: 22

200HP: 62

Heat dissipation (BTU/hr)

200H: 58.75

200HP: 191.9

Physical Specifications

Item

Dimensions (WxDxH)(mm/in.):

272 x 187 x 36/10.7 x 7.36 x 1.42

Weight (kg/lb.):

200H: 1.52/3.34

200HP: 1.52/3.35

Packing

Dimensions (WxDxH)(mm/in.):

427 x 247 x 73/16.81 x 9.72 x 2.87

Weight (kg/lb.):

200H: 2.43/5.36

200HP: 2.68/5.92

Included accessories

Power adapter

Power cord (200HP)

RJ-45 - RS-232 cable for console connection

Rack mounting kit (optional, by regions)

Environmental Specifications

Operating

Temperature: 0°C to 40°C / 32°F to 104°F

Humidity: 10% to 90% (non-condensing)

Storage

Temperature: -30°C to 70°C / -22°F to 158°F

Humidity: 10% to 90%(non-condensing)

MTBF (hr)

200H:

40°C/ 306768.409 hr

25°C/ 528037.0106 hr

200HP:

40°C/ 227747.9662 hr

25°C/ 392638.3847 hr

Acoustic noise

-

Certifications

EMC

FCC Part 15 (Class B)

CE EMC (Class B)

RCM (Class B)

BSMI

Safety

LVD (EN62368-1)

BSMI
