ZYXEL Tűzfal 1xWAN(1000Mbps) 4xLAN/DMZ(1000Mbps) 1xPOE+, 1xUSB 3.0 + 1év Gold Security Pack, USGFLEX50HP-EU0102F

Hardware Specifications

WiFi standard

-

10/100/1000 Mbps RJ-45 ports

4 x LAN/DMZ, 1 x WAN

USB 3.0 ports

1

Console port

RJ45

Rack-mountable

-

Fanless

Yes

System Capacity & Performance^*1

SPI firewall throughput (Mbps)^*2

350

VPN throughput (Mbps)

90

VPN IMIX Throughput (Mbps)^*3

40

IPS throughput (Mbps)^*4

-

Anti-Malware throughput (Mbps)^*4

-

UTM throughput (Anti-malware & IPS, Mbps)^*4

-

Max. TCP concurrent sessions^*5

20,000

Recommended gateway-to-gateway IPsec VPN tunnels

5

Max. concurrent IPsec VPN tunnels^*6

20

VLAN interface

8

Wireless Specifications

Standard compliance

-

Wireless frequency

-

Radio

-

SSID number

-

No. of antenna

-

Antenna gain

-

Data rate

-

Key Features

Security Service

Sandboxing^*7

-

Reputation Filter^*7

-

IPS^*7

-

Application Patrol^*7

-

Email Security^*7

-

Web filtering^*7

Yes

SecuReporter^*7

Yes

Collaborative Detection & Response^*7

-

SSL (HTTPS) Inspection

-

Geo Enforcer

Yes

2-Factor Authentication

Yes

Device Insight

Yes

Security Profile Sync^*7

Yes

VPN Features

VPN

IKEv2, IPSec, L2TP/IPSec

Microsoft Azure

Yes

Amazon VPC

Yes

WLAN Management

Default Number of Managed AP

-

Recommend max. AP in 1 AP Group

-

Secure WiFi Service^*7

-

Maximum No. of Tunnel-Mode AP

-

Maximum No. of Managed AP

-

Management & Connectivity

Nebula Cloud Mode

Yes

Nebula Cloud Monitoring Mode

Yes

Device HA Pro

-

Link Aggregation (LAG)

-

Hotspot Management^*7

-

Ticket printer support^*9/ Support Qty (max.)

-

Concurrent device logins (default/max.)^*7*8

64

Power Requirements

Power input

12V DC, 2.0 A max.

Max. power consumption (Watt Max.)

12

Heat dissipation (BTU/hr)

40.92

Physical Specifications

Item

Dimensions (WxDxH)(mm/in.): 216 x 147.3 x 33/8.50 x 5.80 x 1.30

Weight (kg/lb.): 0.88/1.94

Packing

Dimensions (WxDxH)(mm/in.): 276 x 185 x 98/10.87 x 7.28 x 3.86

Weight (kg/lb.): 1.41/3.11

Included accessories

Power adapter

RJ-45 - RS-232 cable for console connection

Environmental Specifications

Operating

Temperature: 0°C to 40°C / 32°F to 104°F

Humidity: 10% to 90% (non-condensing)

Storage

Temperature: -40°C to 70°C/-40°F to 158°F

Humidity: 10% to 90%(non-condensing)

MTBF (hr)

1110,795(at 25?) and 655,130(at 40?)

Acoustic noise

-

Certifications

EMC

FCC Part 15 (Class B)

CE EMC (Class B)

RCM

BSMI

Safety

BSMI

UL
